Paper U Channel Machine with 100mm Working Width 60 Meter Per Min Speed and Numerical Control for U Shape Paper Corner Board Making
-
ハイライト
100mm Working Width Paper U Channel Machine
,60 Meter Per Min Speed U Shape Paper Corner Machine
,Numerical Control Paper Corner Board Making Machine
-
タイプペーパーUチャンネルマシン
-
作業幅100mm
-
PLCブランドシュナイダー、デルタ、シーメンス
-
ビデオ出検提供された
-
マシン名U字型ペーパーコーナーマシン
-
サイズ調節することができる
-
スピード毎分60メートル
-
機械型式U字型紙コーナー製造機
-
起源の場所中国(本土)
-
ブランド名KSPACK
-
証明CE ISO
-
モデル番号KSHJJ
-
最小注文数量1
-
価格19800
-
パッケージの詳細加工木箱パッケージ
-
受渡し時間30日
-
支払条件L/C、D/A、D/P、T/T、ウェスタンユニオン
-
供給の能力月30セット
Paper U Channel Machine with 100mm Working Width 60 Meter Per Min Speed and Numerical Control for U Shape Paper Corner Board Making
Paper U Channel Machine
Cardboard U Shape Craft Paper Edge Protector Paper Corner Board Making Machine for industrial packaging applications.
Technical Specifications
| Paper Angle Protection Specification | Width: 20-100mm Thickness * Length: 50-9000mm |
| Production Speed | 0-30 m/min |
| Host Power | 7.5kW + 4.3kW |
| Control Mode | Numerical Control |
| Raw Material | Surface Paper: 150g-200g Core Paper: 300g-700g |
| Cutting Mode | Servo Tracking Cutting |
| Number of Operators | 1-2 People |
Configuration & Equipment
- Octagonal Device: Seven Groups
- Paper Holder Type: Right Angle Fixed Hoisting Paper Holder
- Glue Supply: Stainless Steel Heating Automatic Circulation Double-Sided Gluing
- Top Paper Device: Stainless Steel, Paper Basin with Transmission
- Host Mesa: Stainless Steel
- Transmission Device: Conveyor Belt and Receiving Table
- Table Cutting Device: Numerical Control
- Application Tools: One Set of Inner Hexagonal Wrenches
Dimensions & Weight
| Host Size (L*W*H) | 5100 * 840 * 1400 mm |
| Coverage Area (L*W) | 32m * 3m |
| Host Weight | 2780 kg |
| Total Weight | 4500 kg |
